RADOX® HPC cables
for powerful charging system

The number of direct-current (DC) fast-charging stations along motorways and in cities is growing dramatically. HUBER+SUHNER is the market leader in high-performance charging for electromobility. It continuously develops innovative solutions based on extensive field experience to meet demanding market requirements.

The origin of HUBER and SUHNER dates back to 1864; the merger in 1968 created a company with a long tradition of innovation, maintaining its leadership in metallic, radio frequency, and optical connectivity for demanding applications.

RADOX high-performance charging®

The RADOX® High Power Charging (HPC) portfolio includes the RADOX HPC200 and the cooled RADOX HPC500 cables, which are designed for charging stations from 50 to 900 kW.  With a charging time of under 15 minutes (80% charge), super-fast charging is within reach even for large battery packs on new trucks.

RADOX® HPC500 – continuous charging at 500 A

RADOX® HPC500 is the latest generation of high-performance charging system that enables continuous charging at 900 A while ensuring safe and easy handling. In addition to the new, further improved cooled cable design, HUBER+SUHNER has also developed a new standardised cooling unit, which has led to a further performance increase and has further simplified the handling of the HPC500 system. This allows continuous 500 A charging with only one cooling unit but two cables simultaneously or up to 900 A with one cable at ambient temperatures up to 40 °C. RADOX® HPC500 constitutes a solution for infrastructure manufacturers and charging station operators with sufficient power reserve for the future. The cable is available with the Combined Charging System CCS2 and CCS1 connectors with the option of customised design and customer logo. The HPC500 cable and connector builds on continuous innovation in cooled cable solutions as well as extensive field experience with more than 50,000 installations of cooled cable systems with Huber+Suhner cables worldwide.

properties:

  • continuous charging up to 900 A
  • 100 km in 3 minutes
  • CCS1 and CCS2

RADOX® HPC200

Due to the excellent properties, unique design, and popularity of the HPC500 cooled cables, Huber+Suhner was asked to offer a solution for uncooled charging stations with a lower power. The outcome is the RADOX® HPC200 system, which provides continuous uncooled charging for electric vehicles at 200 A and short-term charging up to 300 A. Its ergonomic design provides end users with easy handling thanks to its lightweight connector, improved cable flexibility, and sleek shape.

properties:

  • uncooled charging up to 300 A
  • IP67 protection
×
