SENCITY® Road antennas
Building on the success of the SENCITY® Rail antennas for rail applications and following the successful implementation of antennas for tram and trolleybus transport under the SENCITY® Tram brand, Huber+Suhner is now introducing a new range of SENCITY® Road antennas for buses, trucks, heavy goods vehicles, military vehicles, and emergency vehicles.
The origin of HUBER and SUHNER dates back to 1864; the merger in 1968 created a company with a long tradition of innovation, maintaining its leadership in metallic, radio frequency, and optical connectivity for demanding applications.
areas of use
SENCITY® Road Road Low Profile
This low-profile rooftop antenna combines cellular connectivity (2G, 3G, 4G, and 5G), Wi-Fi (including Wi-Fi 6E), and GNSS in one extremely durable housing with a height of only 33 mm. With up to three radiating elements in one housing and mounting through a single hole, installation is quick and easy. The antenna covers a wide frequency band from 694 MHz to 7.125 GHz, enabling high-capacity and reliable data transmission in the most demanding operating conditions.
- low profile: only 33 mm
- 5G and Wi-Fi 6E support
- built-in GNSS with LNA
- one-hole installation
- extreme durability and certification under ISO 16750, ECE-R118
SENCITY® Road MULTI
Antennas designed for applications up to 4x4 MIMO in mobile operator bands, 8x8 MIMO in Wi-Fi networks. They offer various combinations of up to 9 radiating elements in one housing and come with GNSS capability for L1, L2, L5 operation.
- robust multiband rooftop antenna
- supports 2G/3G/4G/5G mobile networks, Wi-Fi 2.4/5 GHz, Wi-Fi 6E
- up to 9 separate ports for 4x4 cellular MIMO and 4x4 Wi-Fi MIMO
- frequency bands 380 MHz to 7.125 GHz
- supplied with dual-band GNSS (L1, L2, L5)
- meets the ISO 16750 automotive standard.
- complies with ECE-R118.
- one-hole mounting, easy cable routing.
SENCITY® Road MIMO
The antennas offer support for MIMO systems, in 2x2 and 3x3 versions, using a single antenna with multiple radiating elements in one common housing, or by installing multiple antennas spaced apart for optimised inter-port isolation.
- up to 5 antenna radiating elements in one housing
- 2x2 MIMO for mobile operator bands
- 2x2 or 3x3 MIMO for Wi-Fi frequencies
- built-in GNSS antenna with an integrated amplifier
- frequency bands 694 MHz to 7.125 GHz
- supports 5G and Wi-Fi 6E
- one-hole mounting
- complies with ISO 16750, ECE-R118
- works without a metal counterweight
SENCITY® Road VHF
The antenna is designed for applications in VHF bands
- frequency bands from 143 to 178 MHz
- complies with EN 50155
- non-flammable pursuant to EN 45545-2
- ECE-R118 approved
SENCITY® Road PUCK
This road antenna is puck shaped and designed for connectivity in SISO applications in the 400 MHz / TETRA bands.
- height 70 mm
- frequency bands 406–428 MHz and 440–470 MHz
- complies with EN 50155
- ECE-R118 approved
- one-hole mounting
documents for download |
|
| Road rooftop antennas catalogue.pdf | |
