SENCITY® Rail antennas
Today, modern trains are not just a means of transport. These are highly sophisticated systems that are constantly communicating with the outside world. And it is the railway antennas that make this communication possible, – whether it is the transfer of data between the train and the control centre, real-time monitoring of the technical condition of the trains, or the provision of reliable Wi-Fi connectivity for passengers.
The origin of HUBER and SUHNER dates back to 1864; the merger in 1968 created a company with a long tradition of innovation, maintaining its leadership in metallic, radio frequency, and optical connectivity for demanding applications.
areas of use
SENCITY® Rail – the benchmark for railway antennas
Huber+Suhner has been developing and manufacturing omnidirectional, high-gain, multi-frequency antennas for rail vehicles for more than 25 years. In the field of rail vehicles, Huber+Suhner antennas are considered the benchmark and the direction of development. The initial SISO antennas were aimed at communication between the vehicle and the GSM-R network, for remote vehicle control, vehicle localisation using GPS. Current MIMO antennas already process signals across the frequency spectrum, i.e., 160 MHz to 7 GHz. We offer 2x2, 4x4 up to 8x8 MIMO antennas with GNSS capability in L1, L2, and L5 subbands.
SENCITY® Rail
A family of omnidirectional rooftop antennas for all types of trains. Designed to meet the special requirements of railway applications, including short-circuit current and high-voltage protection.
- omnidirectional roof railway antennas
- SISO design
- frequency bands VHF, TETRA, GSM-R, 2G/3G/4G/5G , Wi-Fi 2,4/5 GHz, GNSS.
- certified to EN 50155 and EN 45545-2
- built-in GNSS capabilities
SENCITY® Rail Excel
Directional railway rooftop antennas for all types of trains. Designed to meet the special requirements of railway applications, including short-circuit current and high-voltage protection.
- vertically polarised unidirectional and bidirectional variants
- covers services for the 2.4 and 5 GHz Wi-Fi bands
- high-gain 14 dBi
- certified to railway standards EN 50155 and EN 45545-2
SENCITY® Rail Low profile
SISO and MIMO omnidirectional broadband antennas for all types of trains. Ultra-low profile with a maximum height of just 40 mm. Designed to meet the special requirements of railway applications, including short-circuit current and high-voltage protection.
- SISO and MIMO 2x2 variants
- covers the GSM-R, 2G/3G/4G/5G and Wi-Fi 2.4/5/6 GHz bands.
- certified to railway standards EN 50155, EN 45545-2, and NFPA-130
- built-in GNSS capabilities
SENCITY® Rail MIMO
Omnidirectional broadband MIMO rooftop antennas for all types of trains.
- MIMO 2x2 configuration
- covers GSM-R, 2G/3G/4G/5G and Wi-Fi 2.4/5 GHz bands
- optional built-in multiband or dual-band GNSS module
- certified to railway standards EN 50155 and EN 45545-2
SENCITY® Rail MULTI
The 4x4 and 8x8 MIMO omnidirectional broadband antennas are designed for wireless applications, especially mobile operator bands, and to meet the special requirements of railway applications, including protection against short-circuit current and high voltage.
- MIMO 4x4, 2x 4x4
- covers 2G/3G/4G/5G and Wi-Fi 6E bands, GNSS bands including dual-band L1+L2+L5
- robust design
- certified to railway standards EN 50155, EN 45545-2, and NFPA-130>
- low profile: only 90 mm
SENCITY® Rail MIMO +
Dual polarised, omnidirectional 2x2 and 4x4 MIMO rooftop antennas are designed for maximum data throughput
- patented omnidirectional dual polarised technology for maximum data throughput
- MIMO 2x2 and 4x4 configurations
- cover 2G/3G/4G/5G, GNSS bands including dual-band L1+L2+L5
- robust design
- certified to railway standards EN 50155, EN 45545-2, and NFPA-130
- low profile: only 90 mm
documents for download |
|
| Railway rooftop antennas catalogue.pdf | |
